| Parameter Name | Parameter Value |
|---|---|
| Model Number | MKB2-DEXD |
| Place of Origin | Guangdong, China |
| Brand Name | Merryking/OEM |
| Connection | Plug In |
| Input voltage | AC100~240V 50/60Hz |
| Output | 12.5W |
| Certificate | UL/CE/GS/SAA/KC/CB/UKCA/ROHS/PSE/KC |
| Warranty | 24 Months |
| Protection | OVP OCP OTP SCP |
| Test Standard | 100% tested by machine |
| AC plug | US EU UK AU AR Plugs |
| DC connector | 5.52.5/5.52.1/4.01.7/3.51.35/2.5*0.7/Micro/Mini |
| DC Cable | 1M/1.2M/1.5M/Customized |
| Packing | PE Bag+White Box |
Description
| Specification | ||||
| Universal input | 100-240V~50/60Hz | |||
| Input current | 0.4A Max | |||
| General outputs : | ||||
| 3V 1A | 3.3V 1A | 3.3V 2A | 4.2V 1A | 4.2V 2A |
| 5V 0.3A | 5V 0.5A | 5V 1A | 5V 1.2A | 5V 1.5A |
| 5V 2A | 5V 2.1A | 5V 2.4A | 5V 2.5A | 5.1V 2A |
| 5.5V 2A | 6V 0.3A | 6V 0.5A | 6V 1A | 6V 1.5A |
| 6V 2A | 7.5V 1A | 7.5V 1.5A | 7.5V 2A | 8.4V 1A |
| 8.4V 1.5A | 9V 0.5A | 9V 1A | 9V 1.1A | 9V 1.2A |
| 9V 1.3A | 9V 1.5A | 9V 1.66A | 10V 1.2A | 10V 1.5A |
| 12V 0.2A | 12V 0.3A | 12V 0.5A | 12V 0.6A | 12V 0.8A |
| 12V 1A | 12.6V 0.5A | 12.6V 0.8A | 12.6V 1A | 15V 0.3A |
| 15V 0.4A | 15V 0.5A | 15V 0.6A | 15V 0.8A | 15V 1A |
| 16.8V 0.5A | 16.8V 0.7A | 16.8V 0.8A | 18V 0.5A | 18V 0.6A |
| 18V 0.8A | 19V 0.5A | 19V 0.6A | 20V 0.5A | 20V 0.6A |
| 20V 0.75A | 24V 0.25A | 24V 0.3A | 24V 0.5A | 24V 0.6A |
| 24V 0.625A | ||||
